Description
Willis 22″ x 80″ CNC Lathe with Siemens Control, 2280
Inventory # 7337
Model: 2280
Specifications:
Swing Over Bed: 22″
Center Distance: 80″
Max. Z Travel: 75″
Max. Turning Length: 71″
Swing, Cross Slide: 15″
Spindle Bore: 3.1
Spindle RPM, Low: 20 – 200
Middle: 201 – 575
High: 576 – 1,800
Tailstock Travel: 8″
Tailstock Taper: 8 MT
X / Z Rapid, in./min.: 200
Spindle Motor: 15 hp / 440v / 3ph
Mechanical Specifications:
Dimensions: 158″ x 79″ x 89″ H
Weight: approx. 7,100 lbs.
Contact us for special pricing and availability
FOB Factory
