Description
GMC 10′ x 10 Gauge Heavy Duty Hydraulic Box & Pan Brake, HBB-1010
Inventory # 6202
Model: HBB-1010
Specifications:
Capacity:
Mild Steel: 10 Gauge
Stainless: 12 Gauge
Box Depth: 6″
Bend Angle: 135°
Beam Opening: 3″
Oil Tank: 32 Gallons
Motor: 10 HP / 230v OR 440v / 3ph (Please Specify Voltage at Time of Order)
Standard Features:
ISO 9001 certified
Hydraulic adjustment for opening
Hydraulic power clamping for workpiece
1″ manual beam adjustment (front and back)
Heavy welded all steel construction for maximum rigidity
Hydraulic logic system centrally located and quiet
A wide guidebody ensures strong, stable, smooth and accurate movement
Central control panels on each side for convenient operation
Jog and auto operation modes
Overload protection and disconnect switch
One year warranty for parts
Standard Equipment:
Assorted fingers (2″, 6″, 12″, 18″, 24″)
Angle set up dial
Hydraulic clamping system
26″ Manual Back Gauge
Foot pedal control for hydraulic clamping
(2) safety protection side guards
Mechanical Specifications:
Dimensions: 142″ x 46″ x 66″ H
Weight: approx. 8,050 lbs.
FOB Factory – Contact us for availability
Optional Equipment:
One-Piece Straight Clamping Bar Finger Instead of Assorted Fingers
Safety Fence for Enclosure of the Back Side of the Machine
