Dake 150 Ton Hand Operated Hydraulic H-Frame Press, 150H
Inventory # 4926
Model: 150H
MPN # 907005
Description:
This hand operated hydraulic press features rapid ram return, by-pass hole, and rapid screw traverse of ram, along with an adjustable table and movable work head
Specifications:
Capacity: 150 Tons
Width Between Uprights: 48″
Width Between Table Channels: 12 1/8″
Min. Ram to Table: 5″
Max. Ram to Table: 25″
Ram Travel: 8″
Horizontal Workhead Travel: 27 1/4″
Screw Travel: 8″
Standard Features:
Hand operation for economical performance
By-pass hole prevents excessive ram extension
Rapid screw traverse of ram permits quick, easy movement of the ram by means of a convenient handwheel
Rapid ram return starts as soon as release valve is opened and may be stopped at any point by closing the valve
Adjustable table permits easy vertical movement by means of self-locking hoist
Movable work-head is roller mounted on ball bearings for off-center positioning
Standard Equipment:
Frame
Two Forged Steel V-Blocks
Flat Ram Nose
V-Ram Nose
Pressure Gauge
Self-Locking Table Hoist
Pressure Gauge
Work-Head
Two Forged Steel Table Plates
Mechanical Specifications:
Dimensions: 66″ x 42″ x 95″ H
Weight: approx. 2,750 lbs.
Contact us for special pricing and availability
FOB Factory
