Description
GMC Wet Dust Collector, WDC-2100
Inventory # 7778
Model: WDC-2100
Description:
Wet dust collection systems offer a more safe and efficient method for the collection of hazardous grinding/sanding/cutting dust generated by a variety of processes
Specifications:
Inlet CFM: 2,100
Inlet Opening: 8″
Motor: 5 HP / 208v – 230v, 460v / 3ph
Standard Features:
Cabinet: Made of welded stainless steel construction
Front Door: Easily removed for maintenance and cleaning. Equipped with an explosion relief flap
Electrical Control: Push-button motor starter with thermal overloads
Impeller: Standard, precision balanced, and directly coupled to the motor for maximum CFM with minimum vibration (also stainless steel)
Internal Inducers: A system of internal spray inducers remove dust particles from airflow and causes them to settle in the water tank
Sound Suppressor: The wet dust collector’s unique motor cover design keeps noise level to a minimum
Automatic Water Level Control: Allows users to connect to a water supply line for automatic maintenance of proper operating water level
Mechanical Specifications:
Dimensions: 37″ x 47″ x 76″ H
Weight: approx. 950 lbs.
FOB Factory – Contact us for availability
